Mechanical Standing Seam Profiles
.png/:/cr=t:19.98%25,l:6.91%25,w:89.29%25,h:53.25%25/rs=w:940,h:470,cg:true,m)
200MSAllSeam 2" Mechanical Standing Seam Panel
Seam: 90° or 180° Substrate: 22-, 24-, 26-gauge steel or .032, .040 aluminum Slope: 2:12 or greater slope Support: Wood deck 15/32-inch or greater plywood, steel deck or open framing Coverage: 14 inches or 18 inches
.png/:/cr=t:16.1%25,l:5.66%25,w:94.34%25,h:56.27%25/rs=w:940,h:470,cg:true,m)
150MSAllSeam 1-1/2" Mechanical Standing Seam Panel
Seam: 90° or 180°
Substrate: 22-, 24-, 26-gauge steel,.032, .040 aluminum, or 16oz. and 20oz. copper
Slope: 2:12 or greater slope
Support: Wood deck 15/32-inch or greater plywood; or metal decking
Coverage: 12 inches, 16 inches, or 20 inches
Options: Curve Capable
